SILVERSTONE POWERSUPPLY 750W GOLD ET750

Silverstone 750W+80 Gold Semi-Modular ATX Power Supply Silverstone ET750 Series semi-modular power supplies are certified 80 PLUS Gold for efficient power delivery with great performance . High efficiency with 80 PLUS Gold certification Semi-modular cables facilitate cable management 24/7 continuous power output with 40°C operating temperature Class-leading single +12V rail Silent running 140mm fan with 18 dBA PCIe 8pin and PCIe 6pin connectors support All-black flat cables design Dual EPS 8pin with multiple PCI-E 8 / 6pin connectors support (V1.2) Silverstone Power Supply ET750 Specifications Product No. Silverstone ET750 : SST-ET750-HG Color Black（Lead-Free Paint） Max. DC Output 750W Power density 363W per liter Load Range OUTPUT +3.3V +5V +12V +5VSB -12V MAX.(AMPS) 22A 22A 62A 2.5A 0.3A PEAK (AMPS) / / / 3.0A / MIN.(AMPS) 0A 0A 0A 0A 0A RANGE (%) ±5% ±5% ±5% ±5% ±10% LINE REG.(%) ±1% ±1% ±1% ±1% ±1% RIPPLE(MVP-P) 50mV 50mV 120mV 50mV 120mV Combined +3.3V & +5V 120W Combined +12V 744W Input Voltage 90 ~ 264 Vrms Input Frequency Range 47Hz ~ 63Hz PFC Active PFC（PF>0.9 at full load） Efficiency 87% ~ 90% at 20% ~ 100% loading MTBF 100,000 hours Operating temperature 0°C ~ 40°C Protection Over current protection Over power protection Over voltage protection Short circuit protection Connectors V1.1 1 x 24 / 20-Pin motherboard connector (500mm) 1 x 8 / 4-Pin EPS / ATX 12V connector (750mm) 4 x 8 / 6-Pin PCIe connector (“500mm / 150mm†x 2) 9 x SATA connector (“500mm / 150mm / 150mm†x 3) 3 x 4-Pin Peripheral connector (500mm / 150mm / 150mm) 1 x 4-Pin Floppy connector (500mm / 150mm / 150mm / 150mm) V1.2 1 x 24 / 20-Pin motherboard connector (500mm) *1 x 8-Pin EPS and 1 x 4-Pin + 4-Pin ATX 12V connector (750mm / 150mm) 4 x 8 / 6-Pin PCIe connector (“500mm / 150mm†x 2) 9 x SATA connector (“500mm / 150mm / 150mm†x 3) 3 x 4-Pin Peripheral connector (500mm / 150mm / 150mm) 1 x 4-Pin Floppy connector (500mm / 150mm / 150mm / 150mm) Cooling System Single 140mm silent fan Noise Level 18dBA minimum Certification 80 PLUS Gold Form factor ATX Dimension 150 mm (W) x 86 mm (H) x 160 mm (D) Weight 2 Kg *Dual (CPU) EPS connectors is used in production batch with serial numbers starting 2029 or after. ◠Specifications for Silverstone ET750 presented on this page contains most recent revisions and may differ from those printed on retail boxes or manuals. Check out Datcart Gaming PC in UAE Section includes high quality Power Supplies
