Specification Details
Model New
Graphic Engine NVIDIA® GeForce RTX™ 5090
AI Performance 3593 TOPs
Bus Standard PCI Express 5.0
OpenGL OpenGL® 4.6
Video Memory 32GB GDDR7
Engine Clock OC mode: 2610 MHz
Default mode: 2580 MHz (Boost clock)
CUDA Core 21760
Memory Speed 28 Gbps
Memory Interface 512-bit
Resolution Digital Max Resolution: 7680 x 4320
Interface 2 x HDMI 2.1b (Native)
3 x DisplayPort 2.1b (Native)
HDCP Support: Yes (2.3)
Maximum Display Support 4
NVLink / Crossfire Support No
Accessories 1 x Speedsetup Manual
1 x ROG Graphics Card Holder
1 x ROG Velcro Hook & Loop
1 x ROG Magnet
1 x ROG PCB Ruler
1 x Thank You Card
1 x Adapter Cable (1 to 4)
Software ASUS GPU Tweak III
MuseTree
GeForce Game Ready Driver
Studio Driver
Download all software from the support site
Dimensions Card: 288.46 x 153.7 x 48 mm
Radiator: 400 x 120 x 65 mm
Recommended PSU 1000W
Power Connectors 1 x 16-pin
Slot 2.5 Slot
AURA SYNC ARGB
Notes * Wattage recommendation is based on a fully overclocked GPU & CPU.
* For exact PSU suggestions, use the “Choose By Wattage†feature on the ASUS PSU page.
* All specifications are subject to change without notice.
* Maximum Display Support refers to simultaneous display capability
